 TECHNICAL SPECIFICATIONS
Capacity: From 3KVA to 1000KVA,3Phase+N+E
Type of Connection: Star type suitable for Unbalanced loads
Input Voltage: 300V to 480V Line to Line & 345V to 480V Line to Line,As Specified
Output Voltage: 380V/415V+/-10V,other output optional
Supply Frequency: As input frequency(50Hz)
Output Regulation: +/-1%
Rate of Correction: 70V/Sec
Efficiency: Better than 98%
Wave form distortion: NIL
Effect of Load Power Factor: NIL
Overload Capacity: Motor starting overload upto 200%
Duty: Continuous
Type of Cabinet: Free Standing Unit
Cooling: Air Cooled,Upto 150KVA & Oil Cooled,Above 150KVA
Effect of Spikes: No spike or surges introduced by unit
Monitoring Voltmeter: Digital voltmeter with keypad type selector switch to read Line to Line & Line to Neutral voltage of input & output
ON/Off Switch: A pair of keypad switches connected to Airbrake contactor will be provided for stabilizer On/off operation
Protections: Under/over voltage,Over load,short circuit,Single Phase & Surge
